| MOQ: | 100kg |
| 가격: | 3.5-5.85 USD/KG |
| 표준 포장: | 항해에 적합한 패키지 |
| 배달 기간: | 15 일 |
| 지불 방법: | l/c, t/t |
| 공급 능력: | 500개 톤 / 달 |
The Stainless Steel Type 329 is duplex steel being a combination of austenitic and ferritic types. It can resist pitting as well as corrosion cracking under stress. This type of steel is better to use in forged valve pumps and their components.
Type 329 is also frequently used for centrifugal machines. This type of steel forges better at temperatures around 1250/1050C or 2280/1900F. The parts need to be air-cooled once they are forged. Duplex steel of such grade is very difficult to weld, and hence its machinability is very low.
Common Names: The other names of stainless steel 329 are AISI 329, and UNS S32900.
Executive Standards:
Chemical Properties:
| Elements | Content |
| Iron | 63% |
| Chromium | 28% |
| Nickel | 4.5% |
| Manganese | 2% |
| Molybdenum | 1.5% |
| Silicon | 1% |
| Carbon | 0.10% |
| Phosphorous | 0.040% |
| Sulfur | 0.030% |
Mechanical Properties:
| Properties | Metric |
| Ultimate tensile strength | 725 MPa (105000 psi) |
| Tensile strength, yield (@0.2%) | 550 MPa (79800 psi) |
| Elastic modulus | 190 to 210 GPa (27557 to 30458 Ksi) |
| Poisson’s ratio | 0.27 – 0.30 |
| Elongation (50 mm) | 25% |
| Hardness, Brinell (Knoop) (RB) (RC) (Vickers) | 230 (253) (96) (20) (242) |
Physical Properties: The most notable physical property of SS Type 329 is its density which is 7.80 g/cm3 (0.282 lb/in3
Key Features:
Product Forms Available:
Applications:
FAQ:
Q1: How many countries you already exported?
A1: Exported to more than 50 countries mainly from , UK,Vietnam, Egypt, Turkey, Saudi Arabia,Dubai etc.
Q2: How long will it take to execute my order?
A2: Our normal time to execute the order is 7-20 working days. We will let you know the estimated lead time after payment ASAP.
Q3 Can I have a sample for testing?
A3: Free samples, you just need to pay the freight.
Q4 Do you have inspection for the products before packing?
A4: 100% self-inspection for the products, we put the quality as our first priority.
Q5 Can I have a visit to your factory before the order?
A5: Sure, welcome to visit our factory.
|
|
